AKG CK63 Reference omnidirectional condenser Mic capsule for C480B ULS

The CK63 ULS professional small condenser capsule is characterized by a ruler-flat frequency response. Its consistent hypercardioid polar pattern provides unmatched channel separation, exceptional off-axis rejection and high gain before feedback. The CK63 ULS is widely used in broadcast and recording studios as well as on stages around the world. The CK63 ULS works exclusively with the C480 B pre-amp. To ensure an extra-long life and a reliable connection, the capsule is equipped with large-area, self-cleaning, gold-plated contacts. Careful attention to detail and the highest manufacturing standards make the Ultra Linear Series modular system the choice of experienced technicians worldwide.

General Specifications

• Audio frequency bandwidth 20 - 20000 Hz

• Equivalent noise level 11 dB-A

• Sensitivity 20 mV/Pa

• Signal to Noise 83 dB-A

• Bass cut filter 100 Hz

• Electrical impedance 150 Ohms

• Recommended load impedance 2000 Ohms

• Polar Pattern Hypercardioid

Dimensions

• Height 27 mm

• Diameter 21 mm

Design

• Finish matte black

Audio Output

• Type Balanced XLR

• Gender Male

• Contacts 3-pin

Powering Interface

• Voltage 48 to 48 V

• Current 2 mA
